MORE DURABLE AND MORE DURABLE STABLE
TWO-WAY SHOCKABSORPTION
NEW ADDED ROTATING SHAFT
Two-way shock absorption, more durableMFP PROP
New added rotating shaft, more stable
New propeller tip design
FLIGHT MORE EFFICIENTLY
After many aerodynamic simulations,it adpots a downward-curved winglet design which can effectively improve the vortex distribution of the tip while significantly reducing the vortex intensity,thereby achieving a double-sided improvement in pulling force and force efficiency.
Strengthened propeller root
LOADS INCREASED A LOT
The root structure is strengthened and combined with improved materials, which significantly increases the service life and supports high vertical pulling force and coaxial configuration.
LIGPOWER's unique
DAM-BOARD DESIGN
it acts as a buffer to absorb impact energy with dam-board design and reduce the probability of damage to motors when drones crash
A：Dam-boardCorrugated Spring
rotating shaft
Innovative hub design
SHOCK ABSORPTION AND
LOSS PREVENTION
The upper and lower plates are seated closely.The new stainless steel corrugated spring is added inside to improve the rotational damping and wear life of the gasket throughout its life cycle.
Rotating shaft screw design
REINFORCES AND
ANTI-LOOSENING EFFECTIVELY
The aluminum rotating shaft is designed to prevent the blades from rubbing against the screws.The deep spring washer screws are combined with the self-locking nut to effectively ensure the anti-loosening function of the parts,thus eliminating possible safety implications during the flight of the blades.
