测试参数
| 型号 | 桨 | 油门点 (%) | 电压 (V) | 电流 (A) | 功率 (W) | 转速 (RPM) | 扭矩 (N.m) | 拉力 (g) | 力效 (g/W) | 电机温度 (℃) |
| U8II-X KV85（Alpha 60A 12S ） | MF2815 | 40% | 47.97 | 2.05 | 98 | 1440 | 0.52 | 1492 | 15.15 | 88 （环境温度： 25） |
| 45% | 47.96 | 2.76 | 133 | 1599 | 0.64 | 1853 | 13.98 | |||
| 50% | 47.93 | 3.60 | 172 | 1760 | 0.77 | 2239 | 13.00 | |||
| 55% | 47.91 | 4.62 | 221 | 1918 | 0.91 | 2666 | 12.05 | |||
| 60% | 47.88 | 5.83 | 279 | 2076 | 1.07 | 3157 | 11.30 | |||
| 65% | 47.86 | 7.24 | 347 | 2231 | 1.24 | 3700 | 10.68 | |||
| 70% | 47.82 | 8.80 | 421 | 2386 | 1.40 | 4186 | 9.95 | |||
| 75% | 47.78 | 10.65 | 509 | 2537 | 1.60 | 4724 | 9.28 | |||
| 80% | 47.72 | 12.76 | 609 | 2687 | 1.80 | 5350 | 8.79 | |||
| 85% | 47.65 | 15.08 | 718 | 2836 | 2.00 | 5934 | 8.26 | |||
| 90% | 47.58 | 17.70 | 842 | 2980 | 2.22 | 6580 | 7.81 | |||
| 95% | 47.52 | 20.32 | 966 | 3106 | 2.41 | 7176 | 7.43 | |||
| 100% | 47.47 | 22.34 | 1060 | 3181 | 2.53 | 7548 | 7.12 | |||
| U8II-X KV100（Alpha 60A 12S ） | MF2815 | 40% | 48.00 | 3.47 | 167 | 1723 | 0.73 | 2088 | 12.52 | 95 （环境温度： 25） |
| 45% | 47.98 | 4.66 | 224 | 1909 | 0.90 | 2594 | 11.60 | |||
| 50% | 47.94 | 6.11 | 293 | 2090 | 1.08 | 3145 | 10.74 | |||
| 55% | 47.89 | 7.83 | 375 | 2269 | 1.28 | 3747 | 10.00 | |||
| 60% | 47.83 | 9.83 | 470 | 2446 | 1.48 | 4384 | 9.32 | |||
| 65% | 47.79 | 12.13 | 579 | 2616 | 1.70 | 5028 | 8.68 | |||
| 70% | 47.72 | 14.74 | 703 | 2782 | 1.94 | 5740 | 8.16 | |||
| 75% | 47.64 | 17.67 | 842 | 2939 | 2.16 | 6440 | 7.65 | |||
| 80% | 47.54 | 20.86 | 992 | 3091 | 2.39 | 7115 | 7.17 | |||
| 85% | 47.46 | 24.37 | 1156 | 3230 | 2.62 | 7771 | 6.72 | |||
| 90% | 47.35 | 28.12 | 1331 | 3357 | 2.82 | 8403 | 6.31 | |||
| 95% | 47.25 | 31.56 | 1491 | 3454 | 2.99 | 8903 | 5.97 | |||
| 100% | 47.22 | 33.22 | 1569 | 3491 | 3.05 | 9082 | 5.79 | |||
| U8II-X KV150（Alpha60A 6S ） | MF2815 | 40% | 23.93 | 3.39 | 81 | 1344 | 0.45 | 1218 | 15.02 | 71 （环境温度： 25） |
| 45% | 23.89 | 4.47 | 107 | 1491 | 0.55 | 1505 | 14.08 | |||
| 50% | 23.87 | 5.85 | 140 | 1635 | 0.66 | 1845 | 13.22 | |||
| 55% | 23.80 | 7.43 | 177 | 1780 | 0.78 | 2194 | 12.41 | |||
| 60% | 23.76 | 9.27 | 220 | 1918 | 0.91 | 2584 | 11.73 | |||
| 65% | 23.70 | 11.37 | 269 | 2053 | 1.04 | 2988 | 11.09 | |||
| 70% | 23.64 | 13.75 | 325 | 2186 | 1.18 | 3424 | 10.54 | |||
| 75% | 23.57 | 16.46 | 388 | 2316 | 1.33 | 3902 | 10.06 | |||
| 80% | 23.49 | 19.18 | 450 | 2432 | 1.47 | 4276 | 9.49 | |||
| 85% | 23.44 | 21.33 | 500 | 2514 | 1.57 | 4587 | 9.17 | |||
| 90% | 23.38 | 24.06 | 562 | 2609 | 1.69 | 4940 | 8.78 | |||
| 95% | 23.35 | 25.03 | 584 | 2641 | 1.74 | 5084 | 8.70 | |||
| 100% | 23.35 | 24.99 | 583 | 2640 | 1.73 | 5056 | 8.67 | |||
| U8II-X KV190（Alpha 60A 6S ） | MF2815 | 40% | 23.89 | 5.22 | 125 | 1571 | 0.64 | 1674 | 13.42 | 95 （环境温度： 25） |
| 45% | 23.83 | 7.01 | 167 | 1741 | 0.78 | 2095 | 12.54 | |||
| 50% | 23.78 | 9.17 | 218 | 1906 | 0.93 | 2537 | 11.63 | |||
| 55% | 23.72 | 11.67 | 277 | 2066 | 1.08 | 3037 | 10.98 | |||
| 60% | 23.63 | 14.55 | 344 | 2220 | 1.25 | 3542 | 10.30 | |||
| 65% | 23.54 | 17.90 | 421 | 2373 | 1.42 | 4052 | 9.61 | |||
| 70% | 23.44 | 21.62 | 507 | 2518 | 1.60 | 4586 | 9.05 | |||
| 75% | 23.32 | 25.71 | 600 | 2658 | 1.78 | 5141 | 8.57 | |||
| 80% | 23.20 | 30.31 | 703 | 2794 | 1.96 | 5704 | 8.11 | |||
| 85% | 23.06 | 35.21 | 812 | 2921 | 2.14 | 6249 | 7.70 | |||
| 90% | 22.94 | 39.42 | 904 | 3018 | 2.29 | 6667 | 7.37 | |||
| 95% | 22.92 | 41.21 | 944 | 3053 | 2.34 | 6854 | 7.26 | |||
| 100% | 22.90 | 41.10 | 941 | 3048 | 2.34 | 6847 | 7.27 | |||
| 注意：电机温度为100%油门下电机运行10分钟的机壳温度。 （该数据由T-MOTOR自主平台测试所得，仅作为选型参考，最终解释权归T-MOTOR所有。） | ||||||||||
