Test Data
| Type | Propeller | Voltage (V) | Throttle (%) | Current (A) | RPM | Thrust (g) | Power (W) | Efficiency (g/W) | Torque (N*m) | Operating Temperature (℃) |
| 505-X KV320（Alpha 60A 6S） | MF2211 | 40% | 23.83 | 7.71 | 184 | 2612 | 0.52 | 1953 | 10.62 | 88 （Ambient temperature： 25） |
| 45% | 23.77 | 10.28 | 244 | 2884 | 0.64 | 2395 | 9.80 | |||
| 50% | 23.70 | 13.31 | 315 | 3147 | 0.76 | 2851 | 9.04 | |||
| 55% | 23.62 | 16.75 | 396 | 3399 | 0.88 | 3328 | 8.41 | |||
| 60% | 23.53 | 20.61 | 485 | 3641 | 1.01 | 3817 | 7.87 | |||
| 65% | 23.42 | 24.98 | 585 | 3873 | 1.14 | 4318 | 7.38 | |||
| 70% | 23.31 | 29.68 | 692 | 4092 | 1.27 | 4824 | 6.97 | |||
| 75% | 23.19 | 34.82 | 807 | 4296 | 1.40 | 5328 | 6.60 | |||
| 80% | 23.05 | 40.29 | 929 | 4491 | 1.53 | 5819 | 6.26 | |||
| 85% | 22.92 | 45.99 | 1054 | 4672 | 1.65 | 6289 | 5.97 | |||
| 90% | 22.76 | 52.25 | 1190 | 4849 | 1.77 | 6764 | 5.69 | |||
| 95% | 22.68 | 55.70 | 1263 | 4935 | 1.83 | 7014 | 5.55 | |||
| 100% | 22.66 | 56.45 | 1279 | 4952 | 1.84 | 7050 | 5.51 | |||
| 505-X KV380（Alpha 60A 6S ） | MF1806 | 40% | 23.90 | 5.05 | 120.79 | 3235 | 0.25 | 1169 | 9.68 | 83 （Ambient temperature： 25） |
| 45% | 23.86 | 6.58 | 157.12 | 3593 | 0.30 | 1443 | 9.18 | |||
| 50% | 23.82 | 8.51 | 202.65 | 3952 | 0.37 | 1742 | 8.60 | |||
| 55% | 23.76 | 10.70 | 254.17 | 4305 | 0.43 | 2069 | 8.14 | |||
| 60% | 23.70 | 13.24 | 313.79 | 4647 | 0.50 | 2415 | 7.70 | |||
| 65% | 23.63 | 16.13 | 381.22 | 4986 | 0.58 | 2783 | 7.30 | |||
| 70% | 23.56 | 19.39 | 456.66 | 5312 | 0.65 | 3162 | 6.92 | |||
| 75% | 23.47 | 23.06 | 541.16 | 5633 | 0.73 | 3558 | 6.57 | |||
| 80% | 23.37 | 27.08 | 632.99 | 5944 | 0.82 | 3966 | 6.27 | |||
| 85% | 23.27 | 31.48 | 732.34 | 6245 | 0.90 | 4376 | 5.98 | |||
| 90% | 23.15 | 36.21 | 838.28 | 6535 | 0.99 | 4790 | 5.71 | |||
| 95% | 23.04 | 41.00 | 944.53 | 6802 | 1.07 | 5190 | 5.49 | |||
| 100% | 23.01 | 41.88 | 963.92 | 6848 | 1.08 | 5260 | 5.46 | |||
| Note: The motor temperature refers to the casing temperature after running at 100% throttle for 10 mins. (The above data is obtained by LIGPOWER independent platform test and is only for reference. The final interpretation right belongs to LIGPOWER.) | ||||||||||
