Test Data
| Type | Propeller | Voltage (V) | Throttle (%) | Current (A) | RPM | Thrust (g) | Power (W) | Efficiency (g/W) | Torque (N*m) | Operating Temperature (℃) |
| 705-X KV125（Alpha 80A 12S ） | MF2614 | 40% | 47.97 | 4.67 | 224 | 2155 | 0.81 | 2480 | 11.07 | 74 （Ambient temperature： 25） |
| 45% | 47.92 | 6.26 | 300 | 2392 | 1.00 | 3081 | 10.27 | |||
| 50% | 47.88 | 8.16 | 391 | 2627 | 1.19 | 3717 | 9.52 | |||
| 55% | 47.82 | 10.42 | 498 | 2863 | 1.41 | 4393 | 8.82 | |||
| 60% | 47.74 | 13.07 | 624 | 3091 | 1.64 | 5142 | 8.24 | |||
| 65% | 47.63 | 16.11 | 767 | 3314 | 1.89 | 5952 | 7.76 | |||
| 70% | 47.55 | 19.54 | 929 | 3536 | 2.15 | 6757 | 7.27 | |||
| 75% | 47.45 | 23.45 | 1113 | 3752 | 2.43 | 7701 | 6.92 | |||
| 80% | 47.33 | 27.79 | 1315 | 3967 | 2.71 | 8582 | 6.52 | |||
| 85% | 47.19 | 32.68 | 1542 | 4177 | 2.99 | 9506 | 6.17 | |||
| 90% | 47.05 | 38.06 | 1791 | 4381 | 3.28 | 10521 | 5.88 | |||
| 95% | 46.96 | 40.88 | 1920 | 4481 | 3.44 | 11037 | 5.75 | |||
| 100% | 46.95 | 41.24 | 1936 | 4492 | 3.44 | 11081 | 5.72 | |||
| Note: The motor temperature refers to the casing temperature after running at 100% throttle for 10 mins. (The above data is obtained by T-MOTOR independent platform test and is only for reference. The final interpretation right belongs to T-MOTOR.) | ||||||||||
