T-HOBBY AMZ 21*10 Lightweight Propeller for 72-76" 3D Aircraft

95.90

Available points: 96 Points Points reward: 95 Points

Quantity:

95.90

Free Shipping by DHL/UPS Express

  • Detail information
  • Specifications
amz series detail1

AMZ 21X10

AM740 KV185/AM780 KV190+AM156A

amz series detail2

AMZ 21x10 Power System Matching

AM156A 5~14S

ESC

AM740 KV185 14.8kg

MOTOR&MAX. THRUST

AM780 KV190 16.2kg

MOTOR&MAX. THRUST

72''~76'' 32~38cc

3D aircraft

12S 3300~4200mAh

Recommended battery

Technical Drawing


Specification Export to Excel
Model NO.AMZ21x10Operating Environment Temperature-30~50℃
Diameter24 InchStorage Temperature/Humidity-10~50℃/<85%
Pitch10 InchPackage Size590x70x35mm
Weight(Single Blade)45gPackage Weight195g
MaterialCF+EpoxyRecommended Thrust/RPM11.1kg/6710 RPM
Attribute ClassificationIntegrated PropellerRecommended Max Thrust/RPM19.1kg/8920 RPM
Analysis Chart


Packing List


Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to " onlinesales@ligpower.com " in time.
Note

(1)Prop marked with "L" is for CW which "R" for CCW (aerial view).

(2)Please be careful when using the propellers as the spinning propellers may cause serious injury.

(3)Propeller structural strength has been rigorously tested. Use within the recommended maximum thrust range. Exceeding the ultimate thrust limit will damage the propeller blades.Do not test blade strength by hand-bending, as this does not replicate actual flight stress conditions and may cause blade damage.

(4)Please make sure all the accessories are mounted properly.

(5)Please check on the propellers before flight and make sure they are in good condition. Please replace propellers with new ones if fault is found with them.

(6)Propeller storage requirements:    •Avoid corrosive gases and hazardous environments.    •Maintain ambient conditions within: Temperature range: -10°C to 50°C Relative humidity: ≤85% RH    •Strictly adhere to these parameters during long-term storage.

(7)Please apply anaerobic screw locking glue of medium or above strength when install propellers onto motors.

(8)Please use the propellers in compliance with local laws and regulations.
