T-HOBBY Velox F7 SE+V50A SE HD Stack

BETAFLIGHT
LATEST WIRING STANDARD

Unified socket standards, no longer worry
about plugging in the wrong wire

UNLOCKING
THE FULL FUNCTIONS

• Wireless Bluetooth
• Dual BEC
• HD&Analog
• 8 Motors Support
• PIT function
• Voltage Selection
• All Sockets
• 128M Black Box
• Built-in Barometer

BLUETOOTH WIRELESS
PARAMETER ADJUSTMENT

THE SECOND-GENERATION
POWER SOLUTION ENSURES
SMOOTH FLYING

The power supply suppresses noise up to 90db,
making the gyroscope low-noise and low-latency

QUALITY
ASSURANCE

The ESC with preset parameters better
matches with Velox V3 motors, there is no damage in 1,000
real flight tests. (This data is for reference only)

32-bit ESC

The updated 32-bit chip supports high PWM frequency
and extends the flight time of the drone

VELOX F7 SE

SPEC
FC

• ModelVELOX F7 SE
• FirmwareSTM32F7X2
• Unified targetTMTR-T-HOBBYVELOXF7
• MCUSTM32F722
• GyroscopeICM-42688-P(SPI)
• BEC5V2A&10V1.5A
• Uarts6
• BluetoothTMFC
• OSDAT7456E&HD
• Black box128MB
• USBTYPE-C
•
• Specifications
• Weight9g
• Size37.5*40*6.4mm
• Installation hole30.5*30.5/φ4mm
• Input voltage12-27V(3-6S)
• Typical application170-450multi-rotor

VELOX F7 SE

SPEC
ESC

• MCUAT32F421
• Input voltage3-6S
• Current50A
• Peak Current (5S)60A
• Size41*44.4*5.8mm
• Mounting holes30.5*30.5/Φ4mm
• Weight12.3g
•
•
